ZB38KQE Box Type Compressor R404A Refrigeration Unit

  • Item NO.:

    ZB38KQE
  • Order(MOQ):

    1
  • Payment:

    EX-WORK
  • Market Price:

    1095
  • Price Range:

    1095 - 1296
  • Product Origin:

    USA
  • Color:

    White
  • Shipping Port:

    Guangzhou
  • Lead Time:

    15 to 20 days

ZB38KQE Compressor For Condensing Unit


Product description:


BUW-B series box-type condensing units have the following characteristics


1.Products adopt horizontal box- type structure,high wind circle design, excellent appearance.


2.The cover of the case adopts hinge structure,which is easy to maintain and operate.


3.Compressor uses Emerson ZB series and ZSIseries with DTC spray & ZFI series with EVIscroll compressor to meet the application ofmedium temperature and low temperaturerespectively.


4.Adopt U-type condenser, it has large windwardside, small wind resistance and good heat transfer effect.


5.Adopt U-type condenser, it has large windwardside,small wind resistance and good heattransfer effect.


 Copeland ZB38KQE Condensing Unit Catalogue:


Power Supply  380V 50Hz 3phase
Apply Temp. -10 to 5 degree
Compressor Model ZB38KQE
Compressor Max.I(A) 13.5
Fan Voltage (V) 380V 50Hz 3phase
Fan Current (A) 1
Rev.(r/min)910
Suction Line (mm) 19
Liquid Line (mm) 12.7
Size length (mm) 1040
Size Width (mm) 570
Size Height (mm) 1100


Copeland 12.jpgCopeland 15.jpgCopeland 13.jpgCopeland 02.jpg
