17 results found for "air cooled condenser"
  • cool room air-cooled condenser
    cool room air-cooled condenser
    air-cooled condenser for cool room
    RC series air cooled condensers are mainly equipped with large heat transfer demand, large-scale remote-mounted condensing units, piston parallel units and screw units, with good heat transfer capacity.
  • cool room air-cooled condenser
    cool room air-cooled condenser
    air-cooled condenser for cool room
    RC series air cooled condensers are mainly equipped with large heat transfer demand, large-scale remote-mounted condensing units, piston parallel units and screw units, with good heat transfer capacity.
  • air-cooled for cool room
    air-cooled for cool room
    cold room storage air-cooled condenser
    HC series air cooled condensers are mainly equipped with open-type condensing units with scroll compressor, hemertic & semi-hemertic compressor. This air cooled condensers and compressors can be installed together or separately from compressors. Design of High barrel with Side-mounted structure, with high heat transfer capacity.
  • refrigerator copper tube condenser 15HP
    refrigerator copper tube condenser 15HP
    Refrigeration parts copper tube condenser 15HP capacity 36000W
    Air cooled condenser is specially designed for Freon refrigeration equipment and cooled by air. XMK FNF series is suitable for R134a, R22, R404a, R407 and other refrigerants, widely used in freezing, refrigeration, air conditioning, heat pumps and industrial refrigeration. Voltage 380V
  • condenser fin
    condenser fin
    23.6KW Blue Fin Condenser Evaporator Specification
    23.6KW  Cold Storage Condenser Refrigeration  Product description:   HC series air cooled condensers are mainly equipped with open-type condensing units with scrollcompressor, hemertic & semi-hemertic compressor. This air cooled condensers and compressors canbe installed together or sepa rately from compressors .Design of High barrel with Side-mounted Structure.   1.Condensers and compressors can be installed together or separately from compressors. Design of Highbarrel with Side-mounted Structure.   2.Copper tube and corrugated aluminium fins with a distance of2.1 mm are used.   3.Fan specifications adopt φ400mm, φ500mm and φ630mm.   4.Testing pressure 32bar.   5.Adopt high-quality steel plate with powder coating RAL9003 or RAL6001.   6.It can meet the requirements of R22, R134a, R404A, R507A, R407A, R407C,R448A,R449A and other refrig-erants.   7.Retain 1.5bar pressure before leaving factory. HC Series Air Cooled Condenser Data Sheet:   Model HC53/240NT Capacity (KW) 23.6 Surface (㎡) 52.6 Volume (dm) 6.3 Fan Motor Air Flow 7000 Fan Motor Power 480 Fan Motor Current 1.04 dB (A) 53 Connect Pipe Inlet 22 Connect Pipe Outlet 16 Weight (kg) 53
  • XMK Condenser
    XMK Condenser
    Fin Type Evaporator Condenser And Evaporate
    43.9KW Fin Type Evaporator  Product description:   HC series air cooled condensers are mainly equipped with open-type condensing units with scrollcompressor, hemertic & semi-hemertic compressor. This air cooled condensers and compressors canbe installed together or sepa rately from compressors .Design of High barrel with Side-mounted Structure.   1.Condensers and compressors can be installed together or separately from compressors. Design of Highbarrel with Side-mounted Structure.   2.Copper tube and corrugated aluminium fins with a distance of2.1 mm are used.   3.Fan specifications adopt φ400mm, φ500mm and φ630mm.   4.Testing pressure 32bar.   5.Adopt high-quality steel plate with powder coating RAL9003 or RAL6001.   6.It can meet the requirements of R22, R134a, R404A, R507A, R407A, R407C,R448A,R449A and other refrig-erants.   7.Retain 1.5bar pressure before leaving factory. HC Series Air Cooled Condenser Data Sheet:   Model HC98/440NT Capacity (KW) 43.9 Surface (㎡) 97.7 Volume (dm) 11.6 Fan Motor Air Flow 14000 Fan Motor Power 960 Fan Motor Current 2.08 dB (A) 56 Connect Pipe Inlet 28 Connect Pipe Outlet 22 Weight (kg) 75
  • v type air cooled condenser
    v type air cooled condenser
    59.5KW Capacity V Type Air Cooled Condenser
    XMK Factory V Type Air Cooled Condenser  Product description:  RVC series condensers are mainly equipped with large heat transfer demand, large-scaleremote-mounted condensing units, piston parallel units and screw units.1.V-type structure design can be adopted,having larger windward area.2.Copper tube and corrugated aluminium fins with a distance of 2.1 mm are used.3.Fan specifications adopt 500mm and 630mm, divided into 4 poles and 6 poles motor.4.Testing pressure 32bar.5.Adopt high-quality steel plate with powder coating.6.It can meet the requirements of R22, R134a, R404A, R507A, R407A, R407C,R448A,R449Aand other refrigerants.7.Retain 1.5bar pressure before leaving factory.RVC Series Air Cooled Condenser Data Sheet: ModelRVC157/250N Capacity (KW)59.5Surface (㎡)156.5 Volume (dm)18.5Fan Motor Air Flow13200Fan Motor Power1100Fan Motor Current2.2dB (A)55Connect Pipe Inlet2X28Connect Pipe Outlet2X22Weight (kg)175
  • italy stander air cooled condenser
    italy stander air cooled condenser
    Italy stander Air cooled condenser match 313m2 Surface
    RVC series condensers are mainly equipped with large heat trangsfer demand, large-scale remote-mouned condensing unit, piston parallet units and screw units.It features simple structure, small floor coverage, excellent anticorrosion performance and so on. Model condenser max match use to 630 m2 cold room use.
1 2

A total of 2 pages
